H05Z1-K

H05Z1-K

Flexible LSZH cable, suitable for protected fixed installations in public places.

Rated voltage: 300/500 V
Standards: UNE-EN 50525-3-31, EN 50525-3-31, IEC 60227-3
Flexible semi-rigid copper cable, with halogen-free thermoplastic insulation.

Application

Suitable for interior wiring in fixed or light mobile installations, especially in public places or with a high density of people, where protection against fire and hazardous emissions is required. Ideal for electrical panels, luminaires, and control.

Application

Suitable for interior wiring in fixed or light mobile installations, especially in public places or with a high density of people, where protection against fire and hazardous emissions is required. Ideal for electrical panels, luminaires, and control.

      Conductor
      Flexible electrolytic copper conductor class 5
      UNE-EN 50525-3-31, EN  50525-3-31 e IEC 60227-3
      Insulation
      Thermoplastic halogen-free
      EN 50363-7
      Colors

      		 Black, Blue, Brown, Gray, Orange, Pink, Red, Turquoise, Violet, White and Yellow/Green
      Rated voltaje Uo/U 300/500 V
      Test voltaje 2.000 V C.A.
      Maximum conductor temperatura 70ºC
      Flame non-propagation Ok according to UNE-EN 60332-1-2, EN 60332-1-2 e IEC 60332-1-2
      LSHF (Low Smoke Halogen Free)
      		 Ok according to IEC 60754-1 y 60754-2
      Low corrosive gas
      		 Ok according to UNE-EN 50267, EN 50267 e IEC 60754-1 y 60754-2
      Low smoke emisión Ok according to UNE-EN 61034-2, EN 61034-2 e IEC 61034-2
      CE
