H05Z1-R

H05Z1-R

Flexible LSZH cable, suitable for protected fixed installations in public places.

Rated voltage: 300/500 V
Standards: UNE-EN 50525-3-31
Semi-rigid flexible copper cable, with halogen-free thermoplastic insulation.

Application

Intended for fixed installations indoors, in residential buildings, offices, and places of public assembly, where fire safety is required. It offers good handling with greater robustness than the flexible version.

Application

Intended for fixed installations indoors, in residential buildings, offices, and places of public assembly, where fire safety is required. It offers good handling with greater robustness than the flexible version.

      Conductor
      Rigid  copper class 2
      UNE EN 60228 , EN 60228 e IEC 60228
      Insulation
      Thermoplastic halogen-free TI 7
      UNE EN 50363-7  y EN 50363-7
      Colors

      		 Black, Blue, Brown, Gray, Orange, Pink, Red, Turquoise, Violet, White and Yellow/Green
      Rated voltaje Uo/U 300/500 V
      Test voltaje 2.000 V C.A.
      Maximum conductor temperatura 70ºC
      Flame non-propagation Ok according to UNE-EN 60332-1-2, EN 60332-1-2 e IEC 60332-1-2
      LSHF (Low Smoke Halogen Free)  Ok according to IEC 60754-1 y 60754-2
      Low corrosive gas Ok according to UNE-EN 50267, EN 50267, IEC 60754-1 and 60754-2
      Low smoke emisión

      Ok according to UNE-EN 61034-2, EN 61034-2 , IEC 61034-2
      CE
