H05Z1-U

H05Z1-U

Flexible LSZH cable, suitable for protected fixed installations in public places.

Rated voltage: 300/500 V
Standards: UNE-EN 50525-2-31
Semi-rigid flexible copper cable with halogen-free thermoplastic insulation.

Application

Ideal for fixed indoor installations, in embedded or protected conduits, in buildings where high fire safety is required, such as homes, offices, and public centers. Suitable for lighting and control circuits.

Application

Ideal for fixed indoor installations, in embedded or protected conduits, in buildings where high fire safety is required, such as homes, offices, and public centers. Suitable for lighting and control circuits.

      Conductor
      Rigid  copper class 1      		 UNE EN 60228
      Insulation
      Polyolefin  TI 7
      UNE EN 50363-7
      Colors

      		 Black, Blue, Brown, Gray, Orange, Pink, Red, Turquoise, Violet, White and Yellow/Green
      Rated voltaje Uo/U 300/500 V
      Test voltaje 2.000 V C.A.
      Maximum conductor temperatura
      		 70ºC
      Flame non-propagation Ok according to UNE-EN 60332-1-2, EN 60332-1-2 e IEC 60332-1-2
      LSHF (Low Smoke Halogen Free)
      		 Ok according to IEC 60754-1 y 60754-2
      Low corrosive gas Ok according to UNE-EN 50267, EN 50267 e IEC 60754-1 y 60754-2
      Low smoke emisión Ok according to UNE-EN 61034-2, EN 61034-2 e IEC 61034-2
      CE
