H07V-K

H07V-K

Flexible cable, suitable for protected fixed installations.

Rated voltage: 450/750 V
Standards: UNE-EN 50525-2-31
Single-core copper cables with PVC insulation. Rated  voltages U0/U less than or equal to 450/750 V.

Application

For installations in conducts located on surfaces, embedded or in similar closed systems.
Suitable for fixed or protected assembly of lighting and instrumentation and control equipment.

Application

For installations in conducts located on surfaces, embedded or in similar closed systems.
Suitable for fixed or protected assembly of lighting and instrumentation and control equipment.

      Conductor
      Flexible electrolytic copper conductor class 5
      EN 60228 e IEC 60228
      Insulation
      PVC  TI-1
      UNE-EN 50363-3 y EN 50363-3
      Colors

      Black, Blue, Brown, Gray, Orange, Pink, Red, Turquoise, Violet, White and Yellow/Green
      Rated voltage 450/750 V
      Test voltaje 2.500 V C.A.
      Maximum temperatura 70ºC
      CPR Construction
      		 Eca according to EN 50575
      Flame non-propagation OK according to UNE-EN 60332-1-2, EN 60332-1-2 e IEC 60332-1-2
