H07V-R

H07V-R

Rigid PVC cable, suitable for protected fixed installations.

Rated voltage:  450/750 V
Standards: EN 50525-2-31
Conductors without external sheath, PVC insulation, for general use.


Application

Insulated stranded copper conductors, used for fixed protected installations indoors for power supply or lighting from offices, domestic or commercial buildings.

Application

Insulated stranded copper conductors, used for fixed protected installations indoors for power supply or lighting from offices, domestic or commercial buildings.

      Conductor
      Bare copper Class 2      		 EN 60228 e IEC 60228
      Insulation
      PVC TI-1      		 EN 50363-3
      Colors

      Black, Blue, Brown, Gray, Orange, Pink, Red, Turquoise, Violet, White and Yellow/Green
      Rated voltage Uo/U 450/750 V
      Test voltage 2.500 V C.A.
      Maximum conductor temperature 70ºC
      CPR Construction Eca according to EN 60228
      Flame non-propagation Ok according to IEC 60332-1-2
