H07V-U

H07V-U

Rigid PVC cable, suitable for protected fixed installations.

Rated voltage: 450/750 V
Standards: EN 50525-2-31
Conductors without external sheath, PVC insulation.

Application

Insulated stranded copper conductors, used for fixed protected installations indoors for power supply or lightings from offices, domestic or commercial buildings.

Application

Insulated stranded copper conductors, used for fixed protected installations indoors for power supply or lightings from offices, domestic or commercial buildings.

      Conductor
      Bare copper Class 1      		 EN 60228 - IEC 60228
      Insulation
      PVC TI-1      		 EN 50363-3
      Colors

      Black, Blue, Brown, Gray, Orange, Pink, Red, Turquoise, Violet, White and Yellow/Green
      Rated voltaje Uo/U 450/750 V
      Test voltaje Rated voltage 2.500 V C.A.
      Maximum temperatura 70ºC
      CPR Construction Eca according to EN 60228
      Flame non-propagation Ok according to IEC 60332-1-2
