RZ1OZ1-K (AS)

RZ1OZ1-K (AS)

Flexible LSZH cable with copper braid shield, suitable for industrial installations.

Rated voltage: 0,6/1 kV.
Standard: IEC 60502-1
High-security flexible copper cables, with cross-linked polyethylene insulation, copper tape shielding, and halogen-free polyolefin sheath.

Application

Suitable for permanent installations in areas with high fire safety requirements, such as tunnels, hospitals, airports, and critical infrastructures. Provides greater mechanical resistance and excellent performance in the event of a fire.

Application

Suitable for permanent installations in areas with high fire safety requirements, such as tunnels, hospitals, airports, and critical infrastructures. Provides greater mechanical resistance and excellent performance in the event of a fire.

      Conductor
      Flexible electrolytic copper conductor class 5      		 EN 60228 - IEC 60228
      Insulation
      Cross-linked Polyethylene (XLPE)
      IEC 60502-1
      Core Identification
      Black numbered



      Inner sheath
      Low-smoke Zero halogen cross-linked polyolefin


      IEC 60502-1

      Shield
      Cu tape 0.10 mm wide
      Overlap ≥ 20%



      Outer sheath
      Polyolefin ST-8

      IEC 60502-1

      Colour
      Black





      Rated voltage Uo/U 0,6/1 kV
      Test voltage  3500 V C.A.
      Maximum conductor temp 90ºC



      Chemical resistant  Ok according to ICEA S-73-532
      UV resistant
      		 Ok according to UNE 211605
      Flame non-propagation
      		 Ok according to IEC 60332-1-2
      Fire non-propagation
      		 Ok according to IEC 60332-3-24
